V Port Ball Valve Collection
- Precise flow control
- Linear flow characteristics
- High CV value
- Anti-cavitation design
- Position indicator
- Durable V-notch ball
- High shutoff capability
- ANSI/PN pressure ratings
- Low torque operation
- Multi-turn actuator ready
Main functions and technical parameters of the product
MeiDe Valve produces V Port Ball Valve Engineered for fibrous/slurry media, this API 607-certified V-port valve features a shear-optimized V-ball with HVOF-sprayed WC-Co coating (HV 1200+) or hard chrome plating (HRC 65-70). Key benefits:
- Precision Flow Control: Equal percentage characteristic (R=50:1) ±2% accuracy
- Self-Cleaning Design: ≥3xDn radius flow path prevents particle buildup (API 6D 5.11 tested)
- Low Torque Operation: Clip spring preload (80-120N) reduces 45% driving torque
- API 622 Compliance: ≤50ppm fugitive emissions via live-loaded packing
- Dual Certification: NACE MR0175 (H₂S resistance) + API 607 fire-safe (650°C/30min)
- Ideal for pulp, wastewater, and slurry systems requiring anti-clog performance.
| Size Range | 2″-48″(50mm-1200mm) | Body Material | CarbonSteel,StainlessSteel,Copper Alloy,alloy steel,etc |
| Temperature Range | -196 to 425Â degree | Stem Material | Staniless Steel |
| Pressure Ratings | Class 150 to Class 600,PN 2.5 to PN110,10K-20K | Shutoff Rating | Zero Leakage |
| TrimMaterial | CarbonSteel,StainlessSteel,CopperAlloy,alloy steel,etc | End connection | FLNG( RF, RTJ), BW, SW, NPT |
| Design Standard | API608,API6D,EN1983,ISO17292,GOST | Flange Standard | ASME B16.5, EN 1092-1,GOST 33259 |
| Testing Standard | EN12266-1,API598,ISO 5208 | Certifications | CE,EAC,SIL3,API6D,ISO 19001,API 607,API 6FA |
| Face to Face | API6D,ISO5752,ASMEB16.10,EN558-1 | Fugitive Emissions | ISO 158484-1 |
| Operation | Wench,Worm Gear, Electric, Pneumatic,etc | Seat Material | PTFE,RPTFE,PCTFE,NYLON,DEVLON,PEEK,etc(SoftSeat)coating STL,TCC,NI55,NI60,etc(Metal Seat) |
