Triple Offset Butterfly Valve Collection
- Metal-to-metal seal
- Zero friction operation
- Fire-safe API609
- High-temperature range
- Bi-directional flow
- Zero leakage
- Long-term reliability
- Low maintenance
- ANSI/ASME compliant
- Hygienic design
Main functions and technical parameters of the product
MeiDe Valve producesTriple Offset Butterfly Valve triple offset design ensures metal-to-metal sealing with zero leakage (ISO 15848-1 certified). The 3-eccentric structure eliminates friction, enabling 50,000+ cycles at 600LB. Key advantages:
- Bi-Directional Sealing: Full Class VI shutoff in both flow directions.
- Quick-Change Seat System: Replace seals in 15min without disassembly, reducing downtime by 65%
- Space-Saving: 40% lighter/smaller vs gate valves (ASME 150-600LB).
- Fire-Safe API 609 Compliance: 750°C-rated secondary seal activates post-fire.
- Live-Loaded Packing: Graphite/stainless composite ensures ≤50ppm emissions (-196°C~550°C).
- Integrates 17-4PH anti-blowout stem and conical disc alignment for petrochemical/power plant critical isolation.
| Size Range | 2″-144″(50mm-3600mm) | Body Material | Carbon Steel,Stainless Steel，Nickel Aluminum Bronze,alloy steel,etc |
| Temperature Range | -196 to 550 degree | Stem Material | Staniless Steel |
| Pressure Ratings | Class 150 to Class 1500,PN 2.5 to PN250,10K-20K | Body Style | Lug and Double
Flanged,Wafer,Butt Welded |
| Design Standard | ASME B16.34, Â API 609 | Flange Standard | ASME B16.5,
EN 1092,GOST 33259 |
| Testing Standard | API598,EN12266-1,
ISO 5208 |
Certifications | CE,EAC,SIL3,API 607,API 609,
ISO 19001 |
| Face to Face | ISO 5752,
MSSÂ SP-68,API 609, ASME B16.10,EN558-1 |
Fugitive Emissions | ISO 158484-1 |
| Operation | Wench,Worm Gear, Electric, Pneumatic,etc | Seat Material | SS+Graphite |
