Bellows Sealed Globe Valve Collection
- Double bellows seal
- Zero emissions
- Fire-safe API607
- High-temperature rated
- Rising stem
- Leak-proof design
- Low maintenance
- ANSI standards
- Precise throttling
- Long service life
Main functions and technical parameters of the product
MeiDe Valve produces Bellows Sealed Globe Valve ensures zero leakage (≤1ppm per ISO 15848 AA) with triple-layer Inconel 625/Hastelloy C276 bellows. Key benefits:
- API 6FA Fire-Safe: Maintains ANSI Class IV sealing post-1400°F fire exposure.
- Corrosion Resistance: NACE MR0175 compliant for H₂S/Cl₂ media (≤10% @ 150°C).
- High-Temperature Durability: Welded bellows withstand 450°C/842°F and 25,000kPa (ASME B16.34).
- Precision Flow Control: Parabolic disc achieves ±5% CV accuracy (ISA S75.01).
- Longevity: 10,000+ cycles with 15mm short-stroke actuation. Ideal for chemical, pharma, and high-purity systems.
| Size Range | 1/2″-24″
(15mm-600mm) |
Body Material | CarbonSteel,StainlessSteel,Copper Alloy,alloy steel,etc |
| Temperature Range | -196 to 500Â degree | Stem Material | Staniless Steel |
| Pressure Ratings | Class 150 to Class 2500,PN 2.5 to PN420,10K-20K | Shutoff Rating | Zero Leakage |
| Disc Materials | CarbonSteel,StainlessSteel,CopperAlloy,alloy steel,etc | Body Style | Double Flanged,Butt Weld, |
| Design Standard | ASMEÂ B16.34,BS1873,
DIN3356,API 623 |
Flange Standard | ASME B16.5, EN 1092-1,
GOST 33259,ASME B16.47 |
| Testing Standard | API598,EN12266-1,ISO 5208 | Certifications | CE,EAC,SIL3,API 6FA,
ISO 19001,API 600 |
| Face to Face | ASME B16.10,EN558-1 | Fugitive Emissions | ISO 158484-1 |
| Operation | Wench,Worm Gear, Electric, Pneumatic,etc | Seat Material | Trim Material is Metal to Metal acc to API 600 |
